DEF Grease Reel Packages Click for Larger View
Optional "TR" roller position shown in image.
"SR" roller position is standard.

Call us TODAY at 727-835-0674 or
Toll Free at 800-761-4298

Get A Free Quote!

Hannay DEF Spring Rewind Series Reel Packages

Hannay Diesel Exhaust Fluid Reel Packages include hose and hose stop installed

• Narrow frame and compact mounting base.
• Non-sparking ratchet assembly.
• Declutching arbor to prevent damage from reverse winding.
• Standard inlet: 90° 304 stainless steel full-flow swivel with EPDM seals and available in 1/2", 3/4" or 1" female NPT threads.
• Standard fluid path & outlet: 304 SST fluid path.
• Standard outlets: 1/2", 3/4" or 1" female NPT threads.
• Pressures to 2,000 psi (138 bar).
• Temperatures from -40° F to +212° F (-40° C to +100° C).
• 4-way roller assembly.

Note: *Must specify roller position SR, VR, TR. See below for roller position information.

Click Here for DEF Series Complete Specs

DEF Series Reel Packages

*Scroll to the right on mobile to see entire chart
Part No. Description Size I.D. (in.) Hose Length (ft.) Weight (lbs)
47-63 DEF-450H*
• 304 stainless steel fluid path, SST peroxide cured swivel joint
with EPDM seals, 1/2" female NPT riser, “Tru Blue” DEF hose
with 1/2" male NPT fittings and HS-35 hose stop installed.		 1/2 50 110
47-53 DEF-650H*
• 304 stainless steel fluid path, SST peroxide cured swivel joint
with EPDM seals, 3/4" female NPT riser, “Tru Blue” DEF hose
with 3/4" male NPT fittings and HS-35 hose stop installed.		 3/4 50 127
48-42 DEF-850H*
• 304 stainless steel fluid path, SST peroxide cured swivel joint
with EPDM seals, 1" female NPT riser, “Tru Blue” DEF hose
with 1" male NPT fittings and HS-35 hose stop installed.		 1 50 160

BE SURE TO SPECIFY ROLLER POSITION WHEN ORDERING

On standard spring rewind reels, the hose/cable pays out from the bottom of the reel and to the left when reel is viewed from the swivel joint or collector ring side. Hose/cable rollers are supplied with all spring rewind models and you must specify the roller position when you order. (If roller position is not specified, reels will be shipped with rollers in POSITION SR.)
SR Position
Specify roller position SR when reel will be:
• Installed in the upright position at any point from floor to eye level.
• Installed on a wall with hose/cable to be retracted close to the wall.
• Installed on ceiling, hose/cable will pay out parallel to and close to the ceiling.


Position SR (Standard) Shown:
Swivel Joint Right
VR Position
Specify roller position VR when reel will be:
• Installed in the upright position, hose/cable will be pulled upright from the reel.
• Installed on ceiling to lift hose/cable.
• Installed on a wall with hose/cable to be pulled straight out


Position VR Shown:
Swivel Joint Right
TR Position
Specify roller position TR when reel will be:
• Installed on floor.
• Installed on ceiling with hose/cable to pay out parallel to the ceiling.
• Installed on a wall with hose/cable to be pulled straight down.


Position TR Shown:
Swivel Joint Left
